TRIP EQUATION B =
NO
Description : selection of the “B” logic equation result, which
will be sent to the RL1 output contact
Range : YES/NO
11.1.2 Additional information for the MiCOM P922 – MiCOM P923 relay
TRIP tV2>=
NO
Description : selection of the time-delayed information “tV2>”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV2>>=
NO
Description : selection of the time-delayed information
“tV2>>”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV1<=
NO
Description : selection of the time-delayed information “tV1<”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tV1<<=
NO
Description : selection of the time-delayed information
“tV1<<”, which will be sent to the RL1 output contact
Range : YES/NO
TRIP tF1 =
NO
Description : selection of the time-delayed information “tF1”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tF2 =
NO
Description : selection of the time-delayed information “tF2”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tF3 =
NO
Description : selection of the time-delayed information “tF3”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tF4 =
NO
Description : selection of the time-delayed information “tF4”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tF5 =
NO
Description : selection of the time-delayed information “tF5”,
which will be sent to the RL1 output contact
Range : YES/NO
TRIP tF6 =
NO
Description : selection of the time-delayed information “tF6”,
which will be sent to the RL1 output contact
Range : YES/NO
