Technical Guide P92x/EN FT/E11
User Guide
MiCOM P921-P922-P923 Page 67/110
tAUX1 : 8765432
0000000
Description : allocation of the “tAUX1” information to the
output contacts
Range : 0 or 1 for each output contact
tAUX2 : 8765432
0000000
Description : allocation of the “tAUX2” information to the
output contacts
Range : 0 or 1 for each output contact
CB FAIL : 8765432
0000000
Description : allocation of the “CB Fail” information to the
output contacts
Range : 0 or 1 for each output contact
Note : this information appears if the “CB FAIL” logic input is
energised.
EQU. A : 8765432
0000000
Description : allocation of the “A”equation result to the output
contacts
Range : 0 or 1 for each output contact
EQU. B : 8765432
0000000
Description : allocation of the “B”equation result to the output
contacts
Range : 0 or 1 for each output contact
11.5.3 Additional information for the MiCOM P922 and P923 relay
V2> : 8765432
0000000
Description : allocation of the “V2>”information to the output
contacts
Range : 0 or 1 for each output contact
tV2> : 8765432
0000000
Description : allocation of the “tV2>”information to the output
contacts
Range : 0 or 1 for each output contact
V2>> : 8765432
0000000
Description : allocation of the “V2>>”information to the
output contacts
Range : 0 or 1 for each output contact
tV2>> : 8765432
0000000
Description : allocation of the “tV2>>”information to the
output contacts
Range : 0 or 1 for each output contact
V1< : 8765432
0000000
Description : allocation of the “V1<”information to the output
contacts
Range : 0 or 1 for each output contact
tV1< : 8765432
0000000
Description : allocation of the “tV1<”information to the output
contacts
Range : 0 or 1 for each output contact
V1<< : 8765432
0000000
Description : allocation of the “V1<<”information to the
output contacts
Range : 0 or 1 for each output contact
tV1<< : 8765432
0000000
Description : allocation of the “tV1<<”information to the
output contacts
Range : 0 or 1 for each output contact
