Areva MiCOM P921 - Page 146

P92x/EN FT/E11 Technical Guide
User Guide
Page 68/110 MiCOM P921-P922-P923
F1 : 8765432
0000000
Description : allocation of the “F1”information to the output
contacts
Range : 0 or 1 for each output contact
tF1 : 8765432
0000000
Description : allocation of the “tF1”information to the output
contacts
Range : 0 or 1 for each output contact
F2 : 8765432
0000000
Description : allocation of the “F2”information to the output
contacts
Range : 0 or 1 for each output contact
tF2 : 8765432
0000000
Description : allocation of the “tF2”information to the output
contacts
Range : 0 or 1 for each output contact
F3 : 8765432
0000000
Description : allocation of the “F3”information to the output
contacts
Range : 0 or 1 for each output contact
tF3 : 8765432
0000000
Description : allocation of the “tF3”information to the output
contacts
Range : 0 or 1 for each output contact
F4 : 8765432
0000000
Description : allocation of the “F4”information to the output
contacts
Range : 0 or 1 for each output contact
tF4 : 8765432
0000000
Description : allocation of the “tF4”information to the output
contacts
Range : 0 or 1 for each output contact
F5 : 8765432
0000000
Description : allocation of the “F5”information to the output
contacts
Range : 0 or 1 for each output contact
tF5 : 8765432
0000000
Description : allocation of the “tF5”information to the output
contacts
Range : 0 or 1 for each output contact
F6 : 8765432
0000000
Description : allocation of the “F6”information to the output
contacts
Range : 0 or 1 for each output contact
tF6 : 8765432
0000000
Description : allocation of the “tF6”information to the output
contacts
Range : 0 or 1 for each output contact
CB ALAR : 8765432
0000000
Description : allocation of the “CB Alarm”information to the
output contacts
Range : 0 or 1 for each output contact
Note : this information appears if one of the supervision
thresholds is reached (ex : maximum number of operations).
F OUT OF RANGE: 8765432
0000000
Description : allocation of the “F OUT OF RANGE”information
to the output contacts
Range : 0 or 1 for each output contact
