MiCOM P921-P922-P923 Page 69/110
ACTIVE : 8765432
GROUP 0000000
Description : allocation of the “ACTIVE GROUP”information to
the output contacts
Range : 0 or 1 for each output contact
11.5.4 Additional information for MiCOM P923 only
df/dt1 : 876543
0000000
Description : allocation of the “df/dt1”information to the output
contacts
Range : 0 or 1 for each output contact
df/dt : 876543
0000000
Description : allocation of the “df/dt2”information to the output
contacts
Range : 0 or 1 for each output contact
df/dt3 : 876543
0000000
Description : allocation of the “df/dt3”information to the output
contacts
Range : 0 or 1 for each output contact
df/dt4 : 876543
0000000
Description : allocation of the “df/dt4”information to the output
contacts
Range : 0 or 1 for each output contact
df/dt5 : 876543
0000000
Description : allocation of the “df/dt5”information to the output
contacts
Range : 0 or 1 for each output contact
df/dt6 : 876543
0000000
Description : allocation of the “df/dt6”information to the output
contacts
Range : 0 or 1 for each output contact
EQU. C : 876543
0000000
Description : allocation of the “C” equation result to the output
contacts
Range : 0 or 1 for each output contact
EQU. D : 876543
0000000
Description : allocation of the “D” equation result to the output
contacts
Range : 0 or 1 for each output contact
