Areva MiCOM P921 - Page 150

P92x/EN FT/E11 Technical Guide
User Guide
Page 72/110 MiCOM P921-P922-P923
V>> : BA
00
Description : allocation of the instantaneous information
“V>>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV>> : BA
00
Description : allocation of the time-delayed information
“tV>>” to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V>>> : BA
00
Description : allocation of the instantaneous information
“V>>>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV>>> : BA
00
Description : allocation of the time-delayed information
“tV>>>” to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V0> : BA
00
Description : allocation of the instantaneous information
“V0>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV0> : BA
00
Description : allocation of the time-delayed information “tV0>”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V0>> : BA
00
Description : allocation of the instantaneous information
“V0>>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV0>> : BA
00
Description : allocation of the time-delayed information
“tV0>>” to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V0>>> : BA
00
Description : allocation of the instantaneous information
“V0>>>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV0>>> : BA
00
Description : allocation of the time-delayed information
“tV0>>>” to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
tAUX1 : BA
00
Description : allocation of the time-delayed information
“tAUX1” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tAUX2 : BA
00
Description : allocation of the time-delayed information
“tAUX2” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
CB FAIL : BA
00
Description : allocation of the information “CB FAIL” to the
logic equations (A and/or B).
Range : 0 or 1 for each selected equation
