Technical Guide P92x/EN FT/E11
User Guide
MiCOM P921-P922-P923 Page 73/110
11.7.3 Additional information for the MiCOM P922 relay
V2> : BA
00
Description : allocation of the instantaneous information
“V2>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV2> : BA
00
Description : allocation of the time-delayed information “tV2>”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V2>> : BA
00
Description : allocation of the instantaneous information
“V2>>” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV2>> : BA
00
Description : allocation of the time-delayed information
“tV2>>” to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V1< : BA
00
Description : allocation of the instantaneous information
“V1<” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV1< : BA
00
Description : allocation of the time-delayed information “tV1<”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
V1<< : BA
00
Description : allocation of the instantaneous information
“V1<<” to the logic equations (A and/or B).
Range : 0 or 1 for each selected equation
tV1<< : BA
00
Description : allocation of the time-delayed information
“tV1<<” to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
F1 : BA
00
Description : allocation of the instantaneous information “F1”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
tF1 : BA
00
Description : allocation of the time-delayed information “tF1”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
F2 : BA
00
Description : allocation of the instantaneous information “F2”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
tF2 : BA
00
Description : allocation of the time-delayed information “tF2”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
F3 : BA
00
Description : allocation of the instantaneous information “F3”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
tF3 : BA
00
Description : allocation of the time-delayed information “tF3”
to the logic equations (A and/or B)
Range : 0 or 1 for each selected equation
