Technical Guide P92x/EN FT/E11
User Guide
MiCOM P921-P922-P923 Page 75/110
tV<<< : DCBA
0000
Description : allocation of the time-delayed information
“tV<<<” to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V> : DCBA
0000
Description : allocation of the instantaneous information “V>”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tV> : DCBA
0000
Description : allocation of the time-delayed information “tV>”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V>> : DCBA
0000
Description : allocation of the instantaneous information
“V>>” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV>> : DCBA
0000
Description : allocation of the time-delayed information
“tV>>” to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V>>> : DCBA
0000
Description : allocation of the instantaneous information
“V>>>” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV>>> : DCBA
0000
Description : allocation of the time-delayed information
“tV>>>” to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V0> : DCBA
0000
Description : allocation of the instantaneous information
“V0>” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV0> : DCBA
0000
Description : allocation of the time-delayed information “tV0>”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V0>> : DCBA
0000
Description : allocation of the instantaneous information
“V0>>” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV0>> : DCBA
0000
Description : allocation of the time-delayed information
“tV0>>” to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V0>>> : DCBA
0000
Description : allocation of the instantaneous information
“V0>>>” to the logic equations (A and/or B and/or C and/or
D).
Range : 0 or 1 for each selected equation
tV0>>> : DCBA
0000
Description : allocation of the time-delayed information
“tV0>>>” to the logic equations (A and/or B and/or C and/or
D)
Range : 0 or 1 for each selected equation
V2> : DCBA
0000
Description : allocation of the instantaneous information
“V2>” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
