tV2> : DCBA
0000
Description : allocation of the time-delayed information “tV2>”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V2>> : DCBA
0000
Description : allocation of the instantaneous information
“V2>>” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV2>> : DCBA
0000
Description : allocation of the time-delayed information
“tV2>>” to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V1< : DCBA
0000
Description : allocation of the instantaneous information
“V1<” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV1< : DCBA
0000
Description : allocation of the time-delayed information “tV1<”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
V1<< : DCBA
0000
Description : allocation of the instantaneous information
“V1<<” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tV1<< : DCBA
0000
Description : allocation of the time-delayed information
“tV1<<” to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
F1 : DCBA
0000
Description : allocation of the instantaneous information “F1”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tF1 : DCBA
0000
Description : allocation of the time-delayed information “tF1”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
F2 : DCBA
0000
Description : allocation of the instantaneous information “F2”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tF2 : DCBA
0000
Description : allocation of the time-delayed information “tF2”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
F3 : DCBA
0000
Description : allocation of the instantaneous information “F3”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tF3 : DCBA
0000
Description : allocation of the time-delayed information “tF3”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
F4 : DCBA
0000
Description : allocation of the instantaneous information “F4”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
