Technical Guide P92x/EN FT/E11
User Guide
MiCOM P921-P922-P923 Page 77/110
tF4 : DCBA
0000
Description : allocation of the time-delayed information “tF4”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
F5 : DCBA
0000
Description : allocation of the instantaneous information “F5”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tF5 : DCBA
0000
Description : allocation of the time-delayed information “tF5”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
F6 : DCBA
0000
Description : allocation of the instantaneous information “F6”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tF6 : DCBA
0000
Description : allocation of the time-delayed information “tF6”
to the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
df/dt1 : DCBA
0000
Description : allocation of the 1
st
stage information “df/dt1” to
the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
df/dt2 : DCBA
0000
Description : allocation of the 2
nd
stage information “df/dt2” to
the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
df/dt3 : DCBA
0000
Description : allocation of the 3
rd
stage information “df/dt3” to
the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
df/dt4 : DCBA
0000
Description : allocation of the 4
th
stage information “df/dt4” to
the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
df/dt5 : DCBA
0000
Description : allocation of the 5
th
stage information “df/dt5” to
the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
df/dt6 : DCBA
0000
Description : allocation of the 6
th
stage information “df/dt6” to
the logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
tAUX1 : DCBA
0000
Description : allocation of the time-delayed information
“tAUX1” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
tAUX2 : DCBA
0000
Description : allocation of the time-delayed information
“tAUX2” to the logic equations (A and/or B and/or C and/or D).
Range : 0 or 1 for each selected equation
CB ALARM : DCBA
0000
Description : allocation of the information “CB Alarm” to the
logic equations (A and/or B and/or C and/or D)
Range : 0 or 1 for each selected equation
