Technical Guide P92x/EN CT/E11
Modbus Protocol
MiCOM P921-P922-P923 Page 15/118
Address Group Description
Settings
range
Step Unit Format
Default
settings
001B Output information for
threshold : V0>>
0 to FFFF 1 - F16
001C Output information for
threshold : V0>>>
0 to FFFF 1 - F16
001D Output information for
threshold : V2>,
V2>>, V1<, V1<<
0 to FFFF 1 - F48
001E Output information for
threshold f1
0 to 7 1 - F49
001F Output information for
threshold f2
0 to 7 F49
0020 Output information for
threshold f3
0 to 7 F49
0021 Output information for
threshold f4
0 to 7 F49
0022 Output information for
threshold f5
0 to 7 F49
0023 Output information for
threshold f6
0 to 7 F49
0024 Output information for :
"Equation A", "Equation
B", "tAUX1", "tAUX2" and
"Alarm CB Sup."
“Equation C “,
”Equation D”
0 to FFFF 1 - F38
0025 Not acknowledged
alarms: "Equation A",
"Equation B", "tAUX1",
"tAUX2" and "Alarm CB
Sup."
“Equation C”,
“Equation D”
0 to FFFF 1 - F38
0026 Number of disturbance
records available
0 to 5 1 - F31
0027 Trip information (RL1) 0 to 1 0 F1
0028 Memorisation of the
threshold V>
0 to FFFF 1 - F17
0029 Memorisation of the
threshold V>>
0 to FFFF 1 - F17
002A Memorisation of the
threshold V>>>
0 to FFFF 1 - F17
002B Memorisation of the
threshold V<
0 to FFFF 1 - F17
002C Memorisation of the
threshold V<<
0 to FFFF 1 - F17
002D Memorisation of the
threshold V<<<
0 to FFFF 1 - F17
002E Not acknowledged
alarms : Flag 1
F36
002F Not acknowledged
alarms : Flag 2
F37
