Areva MiCOM P921 - Page 212

P92x/EN CT/E11 Technical Guide
Modbus Protocol
Page 22/118 MiCOM P921-P922-P923
Product
Address Group Description Settings range Step Unit Format
Default
settings
P921 P922/ P923
01A2 Allocation of
the information
to the Logic
equations
tV< 0 - 3
or
0 - 15
1 - F54 0 X X X
01A3 tV<< 0 - 3 or
0 - 15
1- F540 XXX
01A4 tV<<< 0 - 3 or
0 - 15
1- F540 XXX
01A5 tV> 0 - 3 or
0 - 15
1- F540 XXX
01A6 tV>> 0 - 3 or
0 - 15
1- F540 XXX
01A7 tV>>> 0 - 3 or
0 - 15
1- F540 XXX
01A8 tVo> 0 - 3 or
0 - 15
1- F540 XXX
01A9 tVo>> 0 - 3 or
0 - 15
1- F540 XXX
01AA tVo>>> 0 - 3 or
0 - 15
1- F540 XXX
01AB V< 0 - 3 or
0 -15
1- F540 XXX
01AC V<< 0 - 3 or
0 - 15
1- F540 XXX
01AD V<<< 0 - 3 or
0 - 15
1- F540 XXX
01AE V> 0 - 3 or
0 - 15
1- F540 XXX
01AF V>> 0 - 3 or
0 - 15
1- F540 XXX
01B0 V>>> 0 - 3 or
0 - 15
1- F540 XXX
01B1 Vo> 0 - 3 or
0 - 15
1- F540 XXX
01B2 Vo>> 0 - 3 or
0 - 15
1- F540 XXX
01B3 Vo>>> 0 - 3 or
0 - 15
1- F540 XXX
01B4 tAux 1 0 - 3 or
0 - 15
1- F540 XXX
01B5 tAux 2 0 - 3 or
0 - 15
1- F540 XXX
01B6 tV2> 0 - 3 or
0 - 15
1- F540 X X
01B7 tV2>> 0 - 3 or
0 - 15
1- F540 X X
01B8 tV1< 0 - 3 or
0 - 15
1- F540 X X
01B9 tV1<< 0 - 3 or
0 - 15
1- F540 X X
01BA tf1 0 - 3 or
0 - 15
1- F540 X X
