Technical Guide P92x/EN CT/E11
Modbus Protocol
MiCOM P921-P922-P923 Page 23/118
Product
Address Group Description Settings range Step Unit Format
Default
settings
P921 P922/ P923
01BB tf2 0 - 3 or
0 - 15
1- F540 X X
01BC tf3 0 - 3 or
0 - 15
1- F540 X X
01BD tf4 0 - 3 or
0 - 15
1- F540 X X
01BE tf5 0 - 3 or
0 - 15
1- F540 X X
01BF tf6 0 - 3 or
0 - 15
1- F540 X X
01C0 V2> 0 - 3 or
0 - 15
1- F540 X X
01C1 V2>> 0 - 3 or
0 - 15
1- F540 X X
01C2 V1< 0 - 3 or
0 - 15
1- F540 X X
01C3 V1<< 0 - 3 or
0 - 15
1- F540 X X
01C4 f1 0 - 3 or
0 - 15
1- F540 X X
01C5 f2 0 - 3 or
0 - 15
1- F540 X X
01C6 f3 0 - 3 or
0 - 15
1- F540 X X
01C7 f4 0 - 3 or
0 - 15
1- F540 X X
01C8 F5 0 - 3 or
0 – 15
1- F540 X X
01C9 F6 0 - 3 or
0 - 15
1- F540 X X
01CA CB alarms of
operations, closing
time, operating
time
0 - 3 or
0 - 15
1- F540 X X
01CB df/dt6 0-15 1 - F54 0 X
01CC CB failure 0 - 3 or
0 - 15
1- F540 XXX
01CD to
01CF
Reserved XXX
01D0 Automat. ctrl Trip out contact
configuration (RL1)
1
st
part
0 to 1FFF or
7FFF
1 - F6 0 X X X
01D1 Trip out contact
configuration (RL1)
2
nd
part
0 to 3FF or
FFFF
F7 0 X X
01D2 Latching of the
output contacts (1)
0 to 1FFF or
7FFF
1- F60 XXX
01D3 Latching of the
output contacts (2)
0 to 3FF or
FFFF
F7 0 X X
01D4 Blocking logic 1 0 to 1FFF 1 - F8 0 X X X
01D5 Blocking logic 1
(end)
0 to 3FF or
FFFF
F7 0 X X
