Address Group Description Settings range Step Unit Format
Default
settings
P921 P922/ P923
01D6 Blocking logic 2 0 to 1FFF 1 - F8 0 X X X
01D7 Blocking logic 2
(end)
0 to 3FF or
FFFF
F7 0 X X
01D8 Pick-up timer – A
equation
0 to 36000 1 1/10 sec F1 0 X X X
01D9 Drop-off timer – A
equation
0 to 36000 1 1/10 sec F1 0 X X X
01DA Pick-up timer – B
equation
0 to 36000 1 1/10 sec F1 0 X X X
01DB Drop-off timer – B
equation
0 to 36000 1 1/10 sec F1 0 X X X
01DC Auxiliary timer 1 0 to 20000 1 1/100 sec F1 0 X X X
01DD Auxiliary timer 2 0 to 20000 1 1/100 sec F1 0 X X X
01DE Reserved XXX
01DF Frequency
disturbance record
(Trigger
configuration)
0-2 1 F57 0 X
01E0 Disturbance
records
Pre-time 1 to 25 1 1/10 sec F1 1 X X
01E1 Post-time 1 to 25 1 1/10 sec F1 1 X X
01E2 Disturbance record
(Trigger
Configuration)
0 to 1 1 - F32 0 X X
01E3 CB supervision Number of
operations
0-1 1 - F24 0 X X
01E4 Max number of the
CB operation
0 - 50000 1 - F1 0 X X
01E5 Supervision of the
operating time
0-1 1 - F24 0 X X
01E6 Max operating time 10 to 500 5 1/100 sec F1 10 X X
01E7 Supervision of the
closing time
0-1 1 - F24 0 X X
01E8 Max closing time 10 to 500 5 1/100 sec F1 10 X X
01E9 Time period for
average/max
values
5 to 60 VTA min F42 5 X X
01EA Tripping pulse 10 to 500 5 1/100 sec F1 10 X X X
01EB Closing pulse 10 to 500 5 1/100 F1 10 X X X
01EC Pick-up timer – C
equation
0 to 36000 1 1/10 sec F1 0 X
01ED Drop-off timer – C
equation
0 to 36000 1 1/10 sec F1 0 X
01EE Pick-up timer – D
equation
0 to 36000 1 1/10 sec F1 0 X
01EF Drop-off timer – D
equation
0 to 36000 1 1/10 sec F1 0 X
01F0 to
01F7
Description of the
MiCOM relay for
Courier Comm.
32-127 1 F10 X X X
