P92x/EN CT/E11 Technical Guide
Modbus Protocol
Page 60/118 MiCOM P921-P922-P923
CODE DESCRIPTION Type
Address
Modbus
Cellule
Courier
F67 Code of event and type of the associated value
00
"No event"
-
01
"Remote closing"
F9 013H 021
02
"Remote tripping"
F9 013H 021
03
"Start of disturbance record"
F9 - -
04
"Trip output unlatched"
F9 013H 021
05
"Settings change" address
addres - -
06 "V >" F17
014H¯
023
07 "V >>" F17
015H¯
023
08 "V >>>" F17
016H¯
023
09 "V <" F47
017H¯
023
10 "V <<" F47
018H¯
023
11 "V <<<" F47
019H¯
023
12 "V0 >" F16
01AH¯
023
13 "V0 >>" F16
01BH¯
023
14 "V0 >>>" F16
01CH¯
023
15 "tU >" F17
014H¯
023
16 "tU >>" F17
015H¯
023
17 "tU >>>" F17
016H¯
023
18 "tU <" F47
017H¯
023
19 "tU <<" F47
018H¯
023
20 "tU <<<" F47
019H¯
023
21 "tV0 >" F16
01AH¯
024
22 "tV0 >>" F16
01BH¯
024
23 "tV0 >>>" F16
01CH¯
024
24 "t AUX1" F38
024H¯
024
25 "t AUX2" F38
024H¯
024
26
" t Logical equation A"
F38
024H¯
024
27
" t Logical equation B"
F38
024H¯
024
28
"Logic inputs"
F12
010H¯
020
29
"Blocking logic 1"
F20
011H¯
020
30
"Blocking logic 2"
F20
011H¯
020
31
52a
F20
011H¯
020
32
52b
F20
011H¯
020
33
"CB failure"
F20
011H¯
020
34
"Change of active setting group"
F20 011H 020
35
"trip : tV >"
F13 013H 021
