Technical Guide P92x/EN CT/E11
Modbus Protocol
MiCOM P921-P922-P923 Page 61/118
CODE DESCRIPTION Type
Address
Modbus
Cellule
Courier
36
"trip : tV >>"
F13 013H 021
37
"trip : tV >>>"
F13 013H 021
38
"trip : tV <"
F13 013H 021
39
"trip : tV <<"
F13 013H 021
40
"trip : tV <<<"
F13 013H 021
41
"trip : tV0 >"
F13 013H 021
42
"trip : tV0 >>"
F13 013H 021
43
"trip : tV0 >>>"
F13 013H 021
44
"trip : t AUX1"
F13 013H 021
45
"trip : t AUX2"
F13 013H 021
46
"trip : t logical equation A"
F13 013H 021
47 "trip : t logical equation B " F13 013H 021
48 "Trip of auxiliary output contacts" F39 013H 021
49 "Alarm acknowledgement from the HMI" - - -
50 "Global alarm acknowledgement from the
HMI"
---
51 "Alarm acknowledgement from the
communication"
---
52 "Global alarm acknowledgement from the
communication"
---
53 "Major hardware alarms" F45
00FH¯
022
54 "Minor hardware alarms" F45
00FH¯
022
55 "V2>" F48
01DH¯
024
56 "V2 >>" F48
01DH¯
024
57 "V1 <" F48
01DH¯
024
58 "V1 <<" F48
01DH¯
024
59 "f1" F49
01EH¯
024
60 "f2" F49
01FH¯
024
61 "f3" F49
020H¯
024
62 "f4" F49
021H¯
024
63 "f5" F49
022H¯
024
64 "f6" F49
023H¯
025
65 "tV2>" F48
01DH¯
025
66 "tV2 >>" F48
01DH¯
025
67 "tV1 <" F48
01DH¯
025
68 "tV1 <<" F48
01DH¯
025
69 "tf1" F49
01EH¯
025
