P92x/EN CT/E11 Technical Guide
Modbus Protocol
Page 62/118 MiCOM P921-P922-P923
CODE DESCRIPTION Type
Address
Modbus
Cellule
Courier
70 "tf2" F49
01FH¯
025
71 "tf3" F49
020H¯
025
72 "tf4" F49
021H¯
025
73 "tf5" F49
022H¯
025
74 "tf6" F49
023H¯
025
75 "Frequency out of range" F38
024H¯
025
76 "CB operating time" F38
024H¯
025
77 "Number of operations" F38
024H¯
025
78 "CB closing time" F38
024H¯
025
79 "trip : tV2>" F13 013H 021
80 "trip : tV2 >>" F13 013H 021
81 " trip: tV1 <" F13 013H 021
82 " trip: tV1 <<" F13 013H 021
83 " trip: tf1" F13 013H 021
84 " trip: tf2" F13 013H 021
85 " trip: tf3" F13 013H 021
86 " trip: tf4" F13 013H 021
87 " trip: tf5" F13 013H 021
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
" trip: tf6
“General Start” only for VDEW,otherwise 0
“General trip” only for VDEW, otherwise 0
“Local setting “ only for VDEW, otherwise 0
“ t Logical equation C”
“ t Logical equation D”
“df/dt1”
“df/dt2”
“df/dt3”
“df/dt4”
“df/dt5”
“df/dt6”
“trip: A logical equation”
“trip: B logical equation”
“trip: df/dt1”
“trip: df/dt2”
“trip: df/dt3”
“trip: df/dt4”
F13
F38
F38
F58
F58
F58
F58
F58
F58
F13
F13
F13
F13
F13
F13
013H
024H¯
024H¯
064H¯
064H¯
064H¯
064H¯
064H¯
064H¯
013H
013H
013H
013H
013H
013H
021
025
025
026
026
026
026
026
026
021
021
021
021
021
021
