Technical Guide P92x/EN CT/E11
Modbus Protocol
MiCOM P921-P922-P923 Page 63/118
CODE DESCRIPTION Type
Address
Modbus
Cellule
Courier
106
107
108
“trip: df/dt5”
“trip: df/dt6”
“Latch of the relays “
F13
F13
F34
013H
013H
060H
021
021
N.B. : The double arrow ¯ means the event is generated on event
occurrence and another is generated on event disappearance.
On event occurrence, the corresponding bit of the associated
format is set to "1".
On event disappearance, the corresponding bit of the associated
format is set to "0".
CODE DESCRIPTION
F68 Conversion rules for the fault records
In order to obtain phase and residual voltages at primary VT, apply the following
formula :
Range 57 to 130V :
"Read value".* ("primary phase VT" / " Secondary phase VT ") * 1/63
Range 220 to 480V :
"Read value".* 1/17
Conversion formula (fault magnitude in case of a frequency fault):
1000000/ "Read value"
F69 Code of the fault
00 "No fault"
01 "Remote tripping order"
02 "Trip output contact for : tV>"
03 "Trip output contact for : tV>>"
04 "Trip output contact for : tV>>>"
05 "Trip output contact for : tV<"
06 "Trip output contact for : tV<<"
07 "Trip output contact for : tV<<<"
08 "Trip output contact for : tV0>"
09 "Trip output contact for : tV0>>"
10 "Trip output contact for : tV0>>>"
11 "Trip output contact for : t AUX1"
12 "Trip output contact for : t AUX2"
13 "Trip output contact for : t EQU.A"
14 "Trip output contact for : t EQU.B"
15 "Trip output contact for : tV2>"
16 "Trip output contact for : tV2>>"
17 "Trip output contact for : tV1<"
