Technical Guide P92x/EN CT/E11
Courier Database
MiCOM P921-P922-P923 Page 81/118
3. APPENDIX 1
Col Row Menu Text Data Type Ind
Values
(* : default)
Depend Cell Type Min/Max/Step
00 00 SYSTEM DATA
01 Language Ver>: Indexed String 0
1
2
3
Lang1 (French)
Lang2 (English) *
Lang3 (German)
Lang4 (Spanish)
Setting 0/3/1
02 Password ASCII Password(4 bytes) AAAA Setting 32/127/1
03 Fnlinks: NON IMPLEMENTE
04 Description ASCII Text (6 bytes)
"P922xy" or "P921xy", with :
x = S or –
y = 0 or 1 (V. Gam)
Setting 32/127/1
05 Plant Reference ASCII Text (4 bytes) "Pref" Setting 32/127/1
06 Model Number ASCII Text (16 bytes) "Model Number" Data
07 Firmware Number: NON IMPLEMENTE
08 Serial Number ASCII Text (16 bytes) "Serial Number" Data
09 Frequency Unsigned Integer (2 bytes) XXXX Hz Setting 50/60/10
0A Communication Level Unsigned Integer (2 bytes) 1 Data
0B Address Unsigned Integer (2 bytes) 1* Setting 1/255/1
0C Plant Status Word: NON IMPLEMENTE
0D Control Status Word: NON IMPLEMENTE
0E Setting Group Unsigned Integer Data
0F Load shed Stage: NON IMPLEMENTE
10 Circuit Breaker Control NON IMPLEMENTE
11 Software Reference ASCII Text (16 characters) Data
12-1F Unused, reserved
20 Logic Input Status Binary flag (5 bits / 2 bits) 0: log input 1
1: log input 2
2: log input 3
3: log input 4
4: log input 5
Data
