P92x/EN CT/E11 Technical Guide
Courier Database
Page 82/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
21 Relay Output Status Binary flag (9 bits / 5 bits)
0: relay 1 (trip) 1: relay 2 2: relay 3 3: relay 4 4: watchdog relay 5 : relay 5 6 : relay 6 7 : relay 7 8 : relay 8
Data
22
Alarm Binary flag (16 bits)
0: Ana output err 1: Comm err 2: Eeprom err data 3: Vt error 4: Clock error 5: Eeprom err calib 6: Ram error 7 to 15: reserved
Data
23 Pseudo Logic Input Status group 1 Binary flag (16 bits) 0: U<
1: U<< 2: U<<< 3: U> 4: U>> 5: U>>> 6: V0> 7: V0>> 8: t U< 9: t U<< 10: t U<<< 11: t U> 12: t U>> 13: t U>>> 14: t V0> 15: t V0>>
Data
