P92x/EN CT/E11 Technical Guide
Courier Database
Page 84/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
01 00 USER CONTROL
01 Remote control 1 Binary flag (16 bits / 5 bits) 0: Unlock trip cont.*
1: Ack first alarm 2 : Ack all alarms 3 : TRIP 4 : CLOSE 5 : Setting Change 6 : RMS over&max Reset 7 : Reserved 8 : Dist. Rec. Trig 9 : Reserved 10 : Reserved 11 : Reserved 12 : Reserved 13 : Reserved 14 : Reserved 15 : SRAM def . ack
Setting 0/ 31/ 1 or 0/65535/1
02 00 VIEW RECORDS
01 Record number Unsigned Integer (2 bytes) 5 * Setting 1/5/1 02 Occur date Unsigned Integer (2 bytes) 03 Active set group Unsigned Integer (2 bytes) 04 Phase in fault ASCII Text 05 Fault Id ASCII Text 06 Magnitude Courier floating point number 07 Ua magnitude Courier floating point number 08 Ub magnitude Courier floating point number 09 Uc magnitude Courier floating point number 0A V0 magnitude Courier floating point number
03 00 MEASUREMENTS
01 Ua/Uab RMS Courier floating point number Data 02 Ub/Ubc RMS Courier floating point number Data 03 Uc/Uca RMS Courier floating point number Data 04 V0 RMS Courier floating point number Data 05 V1 (Vdirect) Courier floating point number Data
