Technical Guide P92x/EN CT/E11 Courier Database MiCOM P921-P922-P923 Page 85/118
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
06 V2 (Vinv) Courier floating point number Data 07 FREQUENCY Courier floating point number Data 08 Reset Max & Moy RMS 09 MAX RMS Ua/Uab Courier floating point number Data 0A MAX RMS Ub/Ubc Courier floating point number Data 0B MAX RMS Uc/Uca Courier floating point number Data 0C Ua/Uab RMS AVERAGE Courier floating point number Data 0D Ub/Ubc RMS AVERAGE Courier floating point number Data 0E Uc/Uca RMS AVERAGE Courier floating point number Data 0F Frequency Changeof rate Courier floating point number Data
06 00 SW MONITORING
01 SW operation time Courier floating point number 0.0 s Data 02 SW Closing time Courier floating point number Data 03 SW operation nb Unsigned Integer (2 bytes) Data
08 00 TIME:
01 Date/Time IEC870 Time & Date Data 02 Date Format (IEC/no) Indexed String 0 : Private *
1 : IEC
Setting 0 (Private) / 1 (IEC)
0D 00 SETTING CHOICE
01 Voltage wiring type Unsigned Integer (2 bytes) 3 Vpn * / 3 Vpn + Vr / 2
Vpp + Vr / 3 Vpp + Vr
Setting 0/ 3/ 1
02 Protection type (PN-PP) Unsigned Integer (2 bytes) 0 * 0D01 < 2 Setting 0 (P-N) / 1 (P-P)/1 10 FREQUENCY & DF/DT SETTINGS 11 DF/DT cycle number Unsigned Integer (2 bytes) 1 * Setting 1 / 200 / 1 12 DF/DT validation number Unsigned Integer (2 bytes) 4 * Setting 2 / 4 / 2 13 Frequency protection blocking threshold Courier floating point number
5.0 V * if 1000KV Range
else 20.0 V
Setting
5.0 / 130.0 / 0.1 if 1000KV Range else 20.0 / 480.0 / 0.5
