P92x/EN CT/E11 Technical Guide
Courier Database
Page 88/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
11 Max U>> Indexed String 0 0 = NO*/1 = OR/2 = AND Setting 0/2/1 12 Threshold U>> Courier floating point number 130.0 V * if 1000KV Range
else 480.0 V
2111 != 0 Setting 5.0 / 260.0 / 0.1 if
1000KV Range else 20.0 / 960.0 / 0.5
13 Delay U>> Courier floating point number 0.01 s * 2111 != 0 Setting 0 / 599.9 / 0.01 s 14-1F Reserved 20 Stage 3 Overvoltage (Sub Heading) 21 Max U>>> Indexed String 0 0 = NO* / 1 = OR / 2 =
AND
Setting 0/2/1
22 Threshold U>>> Courier floating point number 130.0 V * if 1000KV Range
else 480.0 V
2121 != 0 Setting 5.0 / 260.0 / 0.1 if
1000KV Range else 20.0 / 960.0 / 0.5
23 Delay U>>> Courier floating point number 0.01 s * 2121 != 0 Setting 0 / 599.9 / 0.01 s 24 Hysteresis U> Unsigned Integer (2 bytes) 98 % * 2102 != 0
or 2111 !=0 or 2121 !=0
Setting 95 / 98 / 1 (%)
22 00 EARTH FAULT
01 Stage 1 Overvoltage (Sub Heading) 02 Max V0> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 03 Threshold V0> Courier floating point number 5.0 V * if 1000KV Range
else 20.0 V
2202=1 Setting 5.0 / 130.0 / 0.1 if
1000KV Range else 20.0 / 480.0 / 0.5
04 Delay Type Indexed String 0
1
0: definite time * 1: inverse time
2202=1 Setting 0/1/1
05 TMS Courier floating point number 1.0 * 2204=1 Setting 0.5/100.0/0.5 06 T RESET Courier floating point number 0.1 s * 2204 = 1 Setting 0 / 1000.0 / 0.1 s 07 Delay V0> Courier floating point number 0.04 s * 2204=0 Setting 0 / 599.9 / 0.01 s 08-0F Reserved 10 Stage 2 Overvoltage (Sub Heading) 11 Max V0>> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
