Technical Guide P92x/EN CT/E11 Courier Database MiCOM P921-P922-P923 Page 89/118
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
12 Threshold V0>> Courier floating point number
5.0 V * if 1000KV Range else 20.0 V
2211=1 Setting
5.0 / 130.0 / 0.1 if 1000KV Range else 20.0 / 480.0 / 0.5
13 Delay V0>> Courier floating point number 0.04 s * 2211=1 Setting 0 / 599.9 / 0.01 s 14-1F Reserved 20 Stage 3 Overvoltage (Sub Heading) 21 Max V0>>> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 22 Threshold V0>>> Courier floating point number 5.0 V * if 1000KV Range
else 20.0 V
2221=1 Setting 5.0 / 130.0 / 0.1 if
1000KV Range else 20.0 / 480.0 / 0.5
23 Delay V0>>> Courier floating point number 0.04 s * 2221=1 Setting 0 / 599.9 / 0.01 s
23 00 V2 (Vinverse) OVERVOLTAGE
01 Stage 1 Overvoltage (Sub Heading) 02 Max V2> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 03 Threshold V2> Courier floating point number 130.0 V * if 1000KV Range
else 480.0 V
2302=1 Setting 5.0 / 200.0 / 0.1 if 1000KV
Range else 20.0 / 720.0 / 0.5
04 Delay Type Indexed String
0 1
0: definite time * 1 : inverse time
2302=1 Setting 0/1/1
05 TMS Courier floating point number 1.0 * 2304=1 Setting 0.5/100.0/0.5 06 T RESET Courier floating point number 0.1 s * 2304 = 1 Setting 0 / 1000.0 / 0.1 s 07 Delay V2> Courier floating point number 0.04 s * 2304=0 Setting 0 / 599.9 / 0.01 s 08-0F Reserved 10 Stage 2 Overvoltage (Sub Heading) 11 Max V2>> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 12 Threshold V2>> Courier floating point number 130.0 V * if 1000KV Range
else 480.0 V
2311=1 Setting 5.0 / 200.0 / 0.1 if 1000KV
Range else 20.0 / 720.0 / 0.5
13 Delay V2>> Courier floating point number 0.04 s * 2311=1 Setting 0 / 599.9 / 0.01 s
24 00 V1 (Direct) UNDERVOLTAGE
01 Stage 1 Undervoltage (Sub Heading) 02 Max V1< Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
