Courier Database
Page 92/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
03 Threshold U< Courier floating point number
5.0 V * if 1000KV Range else 20.0 V
4002 != 0 Setting
5.0 / 130.0 / 0.1 if 1000KV Range else 20.0 / 480.0 / 0.5
04 Delay Type Indexed String 0
1
0: definite time * 1 : inverse time
4002 != 0 Setting 0/1/1
05 TMS Courier floating point number 1.0 * 4004=1 Setting 0.5/100.0/0.5 06 T RESET Courier floating point number 0.1 s * 4004 = 1 Setting 0 / 1000.0 / 0.1 s 07 Delay U< Courier floating point number 0.04 s * 4004=0 Setting 0 / 599.9 / 0.01 s 08-0F Reserved 10 Stage 2 Undervoltage (Sub Heading) 11 Max U<< Indexed String 0 0 = NO* / 1 = OR / 2 =
AND
Setting 0/2/1
12 Threshold U<< Courier floating point number 5.0 V * if 1000KV Range
else 20.0 V
4011 != 0 Setting 5.0 / 130.0 / 0.1 if 1000KV
Range else 20.0 / 480.0 / 0.5
13 Delay U<< Courier floating point number 0.01 s * 4011 != 0 Setting 0 / 599.9 / 0.01 s 14-1F Reserved 20 Stage 3 Undervoltage (Sub Heading) 21 Max U<<< Indexed String 0 0 = NO* / 1 = OR / 2 =
AND
Setting 0/2/1
22 Threshold U<<< Courier floating point number
130.0 V * if 1000KV Range else 480.0 V
4021 != 0 Setting
5.0 / 130.0 / 0.1 if 1000KV Range else 20.0 / 480.0 / 0.5
23 Delay U<<< Courier floating point number 0.01 s * 4021 != 0 Setting 0 / 599.9 / 0.01 s 24 Hysteresis U< Unsigned Integer (2 bytes) 102 % * 4002 != 0
or 4011 !=0 or 4021 !=0
Setting 102 / 105 / 1 (%)
41 00 PHASE OVERVOLTAGE
01 Stage 1 Overvoltage (Sub Heading) 02 Max U> Indexed String 0
0 = NO* / 1 = OR / 2 = AND
Setting 0/2/1
