Technical Guide P92x/EN CT/E11 Courier Database MiCOM P921-P922-P923 Page 93/118
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
03 Threshold U> Courier floating point number
130.0 V * if 1000KV Range else 480.0 V
4102 != 0 Setting
5.0 / 200.0 / 0.1 if 1000KV Range else 20.0 / 720.0 / 0.5
04 Delay Type Indexed String 0
1
0: definite time * 1 : inverse time
4102 != 0 Setting 0/1/1
05 TMS Courier floating point number 1.0 * 4104=1 Setting 0.5/100.0/0.5 06 T RESET Courier floating point number 0.1 s * 4104 = 1 Setting 0 / 1000.0 / 0.1 s 07 Delay U> Courier floating point number 0.04 s * 4104=0 Setting 0 / 599.9 / 0.01 s 08-0F Reserved 10 Stage 2 Overvoltage (Sub Heading) 11 Max U>> Indexed String 0 0 = NO* / 1 = OR / 2 =
AND
Setting 0/2/1
12 Threshold U>> Courier floating point number 130.0 V * if 1000KV Range
else 480.0 V
4111 != 0 Setting 5.0 / 260.0 / 0.1 if 1000KV
Range else 20.0 / 960.0 / 0.5
13 Delay U>> Courier floating point number 0.01 s * 4111 != 0 Setting 0 / 599.9 / 0.01 s 14-1F Reserved 20 Stage 3 Overvoltage (Sub Heading) 21 Max U>>> Indexed String 0 0 = NO* / 1 = OR / 2 =
AND
Setting 0/2/1
22 Threshold U>>> Courier floating point number
130.0 V * if 1000KV Range else 480.0 V
4121 != 0 Setting
5.0 / 260.0 / 0.1 if 1000KV Range else 20.0 / 960.0 / 0.5
23 Delay U>>> Courier floating point number 0.01 s * 4121 != 0 Setting 0 / 599.9 / 0.01 s 24 Hysteresis U> Unsigned Integer (2 bytes) 98 % * 4102 != 0
or 4111 !=0 or 4121 !=0
Setting 95 / 98 / 1 (%)
42 00 EARTH FAULT
01 Stage 1 Overvoltage (Sub Heading) 02 Max V0> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
