Technical Guide P92x/EN CT/E11
Courier Database
MiCOM P921-P922-P923 Page 97/118
Col Row Menu Text Data Type Ind
Values
(* : default)
Depend Cell Type Min/Max/Step
08 Threshold df/dt 4 Courier floating point number 1.0 Hz /s * 4607 != 0 Setting -10.0 / 10.0 / 0.1 Hz/s
09 df/dt 5 Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
0A Threshold df/dt 5 Courier floating point number 1.0 Hz /s * 4609 != 0 Setting -10.0 / 10.0 / 0.1 Hz/s
0B df/dt 6 Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
0C Threshold df/dt 6 Courier floating point number 1.0 Hz /s * 460B != 0 Setting -10.0 / 10.0 / 0.1 Hz/s
60 00 AUTOMATISM
01 Trip Configuration Binary (13 bits / 15 bits) 0 * Setting 0/8191/1 or 0/32767/1
02 Trip Configuration (2) Binary (10 bits / 16 bits) 0 * Setting 0/1023/1 or 0/65535/1
03 Latched Configuration Binary (13 bits / 15 bits) 0 * Setting 0/8191/1 or 0/32767/1
04 Latched Configuration (2) Binary (10 bits / 16 bits) 0 * Setting 0/1023/1 or 0/65535/1
05 Blocking 1 Configuration Binary (11 bits) 0 * Setting 0/2047/1
06 Blocking 1 Configuration (2) Binary (10 bits/ 16 bits) 0 * Setting 0/1023/1 or 0/65535/1
07 Blocking 2 Configuration Binary (11 bits) 0 * Setting 0/2047/1
08 Blocking 2 Configuration (2) Binary (10 bits/ 16 bits) 0 * Setting 0/1023/1 or 0/65535/1
61 00 AFFECTATION DES TS
01 Logical input allocation 1 Indexed String
0
1
2
3
4
5
6
7
8
9
10
0: nothing *
1: unlatch
2: 52 a
3: 52 b
4: external CB failure
5: External input 1
6: External input 2
7 : Logic blocking 1
8 : Logic blocking 2
9 : Setting change
10 : Disturbance trig
Setting 0 / 8 / 1 or 0 / 10 / 1
02 Logical input allocation 2 Indexed String 0
1
2
3
4
5
6
7
8
9
10
0: nothing *
1: unlatch
2: 52 a
3: 52 b
4: external CB failure
5: External input 1
6: External input 2
7 : Logic blocking 1
8 : Logic blocking 2
9 : Setting change
10 : Disturbance trig
Setting 0 / 8 / 1 or 0 / 10 / 1
