P92x/EN CT/E11 Technical Guide
Courier Database
Page 96/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values
(* : default)
Depend Cell Type Min/Max/Step
04 F2 Indexed String 0 NO* / 81< / 81> Setting 0/2/1
05 Threshold F2 Courier floating point number 50.00 Hz * if Fn = 50 Hz
else 60.00 Hz
4504 != 0 Setting 40.00 / 60.00 / 0.01 if Fn
= 50 Hz
else 50.00 / 70.00 / 0.01
06 Delay F2 Courier floating point number 0.04 s * 4504 != 0 Setting 0 / 599.9 / 0.01 s
07 F3 Indexed String 0 NO* / 81< / 81> Setting 0/2/1
08 Threshold F3 Courier floating point number
50.00 Hz * if Fn = 50 Hz
else 60.00 Hz
4507 != 0 Setting
40.00 / 60.00 / 0.01 if Fn
= 50 Hz
else 50.00 / 70.00 / 0.01
09 Delay F3 Courier floating point number 0.04 s * 4507 != 0 Setting 0 / 599.9 / 0.01 s
0A F4 Indexed String 0 NO* / 81< / 81> Setting 0/2/1
0B Threshold F4 Courier floating point number 50.00 Hz * if Fn = 50 Hz
else 60.00 Hz
450A != 0 Setting 40.00 / 60.00 / 0.01 if Fn
= 50 Hz
else 50.00 / 70.00 / 0.01
0C Delay F4 Courier floating point number 0.04 s * 450A != 0 Setting 0 / 599.9 / 0.01 s
0D F5 Indexed String 0 NO* / 81< / 81> Setting 0/2/1
0E Threshold F5 Courier floating point number 50.00 Hz * if Fn = 50 Hz
else 60.00 Hz
450D != 0 Setting 40.00 / 60.00 / 0.01 if Fn
= 50 Hz
else 50.00 / 70.00 / 0.01
0F Delay F5 Courier floating point number 0.04 s * 450D != 0 Setting 0 / 599.9 / 0.01 s
10 F6 Indexed String 0 NO* / 81< / 81> Setting 0/2/1
11 Threshold F6 Courier floating point number
50.00 Hz * if Fn = 50 Hz
else 60.00 Hz
4510 != 0 Setting
40.00 / 60.00 / 0.01 if Fn
= 50 Hz
else 50.00 / 70.00 / 0.01
12 Delay F6 Courier floating point number 0.04 s * 4510 != 0 Setting 0 / 599.9 / 0.01 s
46 00 FREQUENCY CHANGE OF RATE
01 df/dt 1 Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
02 Threshold df/dt 1 Courier floating point number 1.0 Hz /s * 4601 != 0 Setting -10.0 / 10.0 / 0.1 Hz/s
03 df/dt 2 Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
04 Threshold df/dt 2 Courier floating point number 1.0 Hz /s * 4603 != 0 Setting -10.0 / 10.0 / 0.1 Hz/s
05 df/dt 3 Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
06 Threshold df/dt 3 Courier floating point number 1.0 Hz /s * 4605 != 0 Setting -10.0 / 10.0 / 0.1 Hz/s
07 df/dt 4 Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
