Technical Guide P92x/EN CT/E11 Courier Database MiCOM P921-P922-P923 Page 95/118
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
07 Delay V2> Courier floating point number 0.04 s * 4304=0 Setting 0 / 599.9 / 0.01 s 08-0F Reserved 10 Stage 2 Overvoltage (Sub Heading) 11 Max V2>> Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 12 Threshold V2>> Courier floating point number
130.0 V * if 1000KV Range else 480.0 V
4311=1 Setting
5.0 / 200.0 / 0.1 if 1000KV Range else 20.0 / 720.0 / 0.5
13 Delay V2>> Courier floating point number 0.04 s * 4311=1 Setting 0 / 599.9 / 0.01 s
44 00 V1 (Direct) UNDERVOLTAGE
01 Stage 1 Undervoltage (Sub Heading) 02 Max V1< Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 03 Threshold V1< Courier floating point number 5.0 V * if 1000KV Range
else 20.0 V
4402=1 Setting 5.0 / 130.0 / 0.1 if 1000KV
Range else 20.0 / 480.0 / 0.5
04 Delay Type Indexed String 0
1
0: definite time * 1: inverse time
4402=1 Setting 0/1/1
05 TMS Courier floating point number 1.0 * 4404=1 Setting 0.5/100.0/0.5 06 T RESET Courier floating point number 0.1 s * 4404 = 1 Setting 0 / 1000.0 / 0.1 s 07 Delay V1< Courier floating point number 0.04 s * 4404=0 Setting 0 / 599.9 / 0.01 s 08-0F Reserved 10 Stage 2 Undervoltage (Sub Heading) 11 Max V1<< Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1 12 Threshold V1<< Courier floating point number
5.0 V * if 1000KV Range else 20.0 V
4411=1 Setting
5.0 / 130.0 / 0.1 if 1000KV Range else 20.0 / 480.0 / 0.5
13 Delay V1<< Courier floating point number 0.04 s * 4411=1 Setting 0 / 599.9 / 0.01 s
45 00 FREQUENCY
01 F1 Indexed String 0 NO* / 81< / 81> Setting 0/2/1 02 Threshold F1 Courier floating point number
50.00 Hz * if Fn = 50 Hz else 60.00 Hz
4501 != 0 Setting
40.00 / 60.00 / 0.01 if Fn = 50 Hz else 50.00 / 70.00 / 0.01
03 Delay F1 Courier floating point number 0.04 s * 4501 != 0 Setting 0 / 599.9 / 0.01 s
