Technical Guide P92x/EN CT/E11 Courier Database MiCOM P921-P922-P923 Page 101/118
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
64 00 TC CONFIGURATION
01 GENERAL TRIP Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 02 CLOSE Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 03 U< Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 04 t U< Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 05 U<< Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 06 t U<< Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 07 U<<< Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 08 t U<<< Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 09 U> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 0A t U> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 0B U>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 0C t U>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 0D U>>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 0E t U>>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 0F V0> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 10 t V0> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 11 V0>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 12 t V0>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 13 V0>>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 14 t V0>>> Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 15 V2> Binary ( 7 bits) 0000000 * Setting 0 / 127 / 1 16 t V2> Binary (7 bits) 0000000 * Setting 0 / 127 / 1 17 V2>> Binary (7 bits) 0000000 * Setting 0 / 127 / 1 18 t V2>> Binary (7 bits) 0000000 * Setting 0 / 127 / 1 19 V1< Binary (7 bits) 0000000 * Setting 0 / 127 / 1 1A t V1< Binary (7 bits) 0000000 * Setting 0 / 127 / 1 1B V1<< Binary (7 bits) 0000000 * Setting 0 / 127 / 1 1C t V1<< Binary (7 bits) 0000000 * Setting 0 / 127 / 1
