P92x/EN CT/E11 Technical Guide
Courier Database
Page 102/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values (* : default)
Depend Cell Type Min/Max/Step
1D F1 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 1E t F1 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 1F F2 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 20 t F2 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 21 F3 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 22 t F3 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 23 F4 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 24 t F4 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 25 F5 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 26 t F5 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 27 F6 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 28 t F6 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 29 DF/DT 1 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 2A DF/DT 2 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 2B DF/DT 3 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 2C DF/DT 4 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 2D DF/DT 5 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 2E DF/DT 6 Binary (7 bits) 0000000 * Setting 0 / 127 / 1 2F tAux 1 Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 30 tAux 2 Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 31 Breaker alarm Binary (7 bits) 0000000 * Setting 0 / 127 / 1 32 Frequency non measurable Binary (7 bits) 0000000 * Setting 0 / 127 / 1 33 Ext. Breaker failure Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 34 Equation A Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 35 Equation B Binary (3 bits / 7 bits)000 * / 0000000 * Setting 0 / 7 / 1 or 0 / 127 / 1 36 Equation C Binary (7 bits) 0000000 * Setting 0 / 127 / 1 37 Equation D Binary (7 bits) 0000000 * Setting 0 / 127 / 1 38 TC Active Setting Group Binary (7 bits) 0000000 *
bit 0 to 6 =0: Group 1 bit 0 to 6 =1: Group 2
Setting 0/127/1
