Technical Guide P92x/EN CT/E11
Courier Database
MiCOM P921-P922-P923 Page 103/118
Col Row Menu Text Data Type Ind
Values
(* : default)
Depend Cell Type Min/Max/Step
39 TC lock setting Binary (3 bits / 7 bits)
000 * / 0000000 *
bit 0 to 2 / bit 0 to 6 =1: TC
Locked
Setting 0 / 7 / 1 or 0/127/1
65 00 CONFIGURATION DES LEDS
01 Led 5 (1) Binary (16 bits) 0 * Setting 0/ 65535/ 1
02 Led 6 (1) Binary (16 bits) 0 * Setting 0/ 65535/ 1
03 Led 7 (1) Binary (16 bits) 0 * Setting 0/ 65535/ 1
04 Led 8 (1) Binary (16 bits) 0 * Setting 0/ 65535/ 1
05 Led 5 (2) Binary (4 bits / 16 bits) 0 * Setting 0/ 15/ 1 or 0/ 65535 /1
06 Led 6 (2) Binary (4 bits / 16 bits) 0 * Setting 0/ 15/ 1 or 0/ 65535 /1
07 Led 7 (2) Binary (4 bits / 16 bits) 0 * Setting 0/ 15/ 1 or 0/ 65535 /1
08 Led 8 (2) Binary (4 bits / 16 bits) 0 * Setting 0/ 15/ 1 or 0/ 65535 /1
09 Led 5 (3) Binary (9 bits / 15 bits) 0 * Setting 0/ 1023/ 1 or 0/32767/1
0A Led 6 (3) Binary (9 bits / 15 bits) 0 * Setting 0/ 1023/ 1 or 0/32767/1
0B Led 7 (3) Binary (9 bits / 15 bits) 0 * Setting 0/ 1023/ 1 or 0/32767/1
0C Led 8 (3) Binary (9 bits / 15 bits) 0 * Setting 0/ 1023/ 1 or 0/32767/1
66 00 ALARMS
01 Instant. alarm self-reset Binary (1 bits) Disabled * / Enabled Setting 0/1/1
02 Battery alarm Binary (1 bits) Disabled * / Enabled Setting 0/1/1
69 00 SW SUPERVISION
01 SW Operating time? Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
02 SW Operating time Courier floating point number 0.10 s* 6901 = 1 Setting 0.10 / 5.0 / 0.05 s
03 SW Closing time ? Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
04 SW Closing time Courier floating point number 0.10 s* 6903 = 1 Setting 0.10 / 5.0 / 0.05 s
05 SW Operating number? Binary (1 bit) 0 Disabled * / Enabled Setting 0/1/1
06 SW Operating number Unsigned Integer (2 bytes) 0 * 6905 = 1 Setting 0/ 50000/ 1
07 TRIP t Courier floating point number 0.1 s* Setting 0.1 / 5.0 / 0.05 s
08 CLOSE t Courier floating point number 0.1 s* Setting 0.1 / 5.0 / 0.05 s
