P92x/EN CT/E11 Technical Guide
Courier Database
Page 104/118 MiCOM P921-P922-P923
Col Row Menu Text Data Type Ind
Values
(* : default)
Depend Cell Type Min/Max/Step
70 00 RECORDER CONTROL (VERSION P922 et >)
01 Start/Trigger recorder Indexed String 0
1
2
Stopped
Trigerred
Running *
Setting 1/2/1
02 Recorder Source Indexed String 0 Samples * Data
20 Pretemps Courier floating point number 0.1 secondes Setting 0.1 / 3.0 / 0.1 s
21 Postemps Courier floating point number 0.1 secondes Setting 0.1 / 3.0 / 0.1 s
22 Disturbance rec. trig Indexed String 0 ON INST* / ON TRIG Setting 0 / 1 / 1
30 Measurement period (Max & Moy) Unsigned Integer (2 bytes) 0 5 mn * Setting 5 / 10 / 15/ 30/ 60 mn
80 00 DISTURBANCE REC (VERSION P922 et >)
01 Record Number Unsigned integer (1 byte) 0* Setting 0/5/1 (selon contexte)
02 Trigger Time IEC870 Time & Date dd/mm/yy hh:mm Data
03 Available Channel Bit Mask
Binary Flag
Indexed String 0
1
2
3
4
11111
"Ua"
"Ub"
"Uc"
"V0"
"Inputs/Outputs"
Data
04 Channel Types Binary Flag 0: digital, 1: analogue 01111 Data
05 Channel Offsets Repeated group of Courier numbers Upload Offsets Data
06 Scaling Factors Repeated group of Courier numbers Upload Scal. Factors Data
07-0F NON IMPLEMENTE - réservé
10 Record Length Integer (2 bytes) Data
11 Trigger position Integer (2 bytes) Data
12 Time Base Courier floating point number Data
13 NON IMPLEMENTED - reserved
14 Upload Timer Repeated group of Integers Data
15-1F NON IMPLEMENTED - reserved
20 Upload Channel 0 Repeated group of Integers Data
21 Upload Channel 1 Repeated group of Integers Data
22 Upload Channel 2 Repeated group of Integers Data
23 Upload Channel 3 Repeated group of Integers Data
