Technical Guide P92x/EN CT/E11
Courier Database
MiCOM P921-P922-P923 Page 105/118
Col Row Menu Text Data Type Ind
Values
(* : default)
Depend Cell Type Min/Max/Step
24 Upload Channel Inputs/Outputs Repeated group of Integer/Bin. flags Data
90 00 AUTOMAT. FLT (VERSION P922 et >)
01 Record number Unsigned Integer (2 bytes)
Setting
(automatic)
02 Occur fault date Unsigned Integer (2 bytes) Data
03 Active set group Unsigned Integer (2 bytes) 1 Data
04 Phase in fault ASCII Text (10 bytes) "PHASE A" Data
05 Fault Id ASCII Text (18 bytes) "U >>" Data
06 Magnitude Courier floating point number 12.34 V Data
07 Ua Magnitude Courier floating point number 12.34 V Data
08 Ub Magnitude Courier floating point number 12.34 V Data
09 Uc Magnitude Courier floating point number 12.34 V Data
0A V0 Magnitude Courier floating point number 12.34 V Data
BF 00 COMM SYSTEM DATA
01 Dist Record Cntrl Ref Menu Cell (2) 0x7000 Data
02 Dist Record Extract Ref Menu Cell (2) 0x8000 Data
03 Setting Transfert Unsigned Integer (2 bytes) 0 * Data 0 / 1 / 1
04 Reset Demand Timers NON IMPLEMENTED
05 Reset Event Report NON IMPLEMENTED
