PRE-OPERATING CHECKS AND OPERATIONS
To assemble the multi-directional wheels it’s necessary to:
1. Remove the tank using both hands, following the direction of the arrow.
2. Remove from the tank the bubble plastic bag which contains the 4 wheels and the cable reel.
3. Reposition the tank as shown in the figure below.
4. Tilt the dehumidifier no more than 45° and remove the 4 rubber plugs, which will be replaced by the 4 wheels.
5. Position the wheels on the 4 holes and push until the wheels are set firmly in place.
6. Lastly attach the cable reel to the rear of the unit, as shown in the figure below.
Make sure the floater and the condensate collection tank are correctly positioned
1. Pull out the tank using both hands and verify the correct position of the floater.
