Argo Service Manual Ducting & Exhaust
Ontario Drive & Gear Limited www.odg.com
PH.(519)- 662-2840 FAX (519)- 662-2421
DE-11
Removing the Muffler (Bigfoot Models)
1. Remove the four fasteners securing the muffler heat shield and remove the shield.
2. Disconnect the extension springs between the tailpipe and muffler and pull the
tailpipe from the engine compartment.
3. Remove the muffler at the engine
Installing the Muffler (Bigfoot Models)
1. Attach the muffler at the engine and torque to specifications
IMPORIMPOR
IMPORIMPOR
IMPOR
TT
TT
T
ANTANT
ANTANT
ANT
Always replace exhaust gaskets when servicing the muffler system.
2. Slip the tailpipe, from the engine compartment side, through the exhaust screen hole
and connect at the muffler with 2 extension springs.
3. Assemble the heat shield to the top of the muffler using the 4 fasteners required.
Spark Arrestors
Cleaning the Spark Arrestor (Only for equipped models)
After operating the engine, do not touch any part of the exhaust system until it has
sufficient time to cool!
Models Equipped with Spark Arrestors.
Conquest All Models
Response Models manufactured from R19647
Bigfoot Models manufactured from BF13028
Vanguard2 Models manufactured from N13436
Vanguard Models manufactured from S13434
Conquest 6x6 Models manufactured from C12747
1. Keep a record of the number of hours of engine use. The spark arrester should be
removed, cleaned and inspected every 50 hours of operation.
