CONTINUOUS CONDENSATE DRAINAGE
The water can be continuously drained when using a PVC hose with an inner diameter of 14 mm (not supplied)
Turn off the appliance and remove the plug before connecting the hose.
Open the small side door, remove the cap and safely connect the hose to the continuous condensate discharge
connection, as shown in the figures below.
The height of the drainage hose must not exceed that of the hole: do not block the drainage hose exit.
When disconnecting the tube, prepare a container to collect the remaining water from the tube.
CONTROL PANEL
Each time the button is pressed, the unit emits an auditory signal.
LED TIMER
LED VELOCITA’ DI
VENTILAZIONE
BASSA-MEDIA-
ALTA
LED TANICA
PIENA
LED PULIZIA
FILTRO
LED
MODALITÀ
LED POWER
