DESCRIPTION OF THE APPLIANCE
FRONT VIEW
REAR VIEW
8
6
7
1
Fix Led: Operation
Flash ON-OFF (1 sec. ON – 1 sec. OFF): Stand-By
Flash ON-OFF (1/6 sec. ON - 1/6 sec. OFF): Full Tank
1) CONTROL PANEL - FUNCTION BUTTONS
FOR OPERATION WITHOUT REMOTE
CONTROL
2) TERMINAL CONNECTOR OF THE AIR
EXPULSION TUBE
3) AIR EXPULSION TUBE
4) REMOTE CONTROL RECEIVER
5) AIR OUTLET
6) INLET GRILLE
7) CONDENSATE DRAIN HOLE
8) OPERATING LED
9) POWER CORD
9) T AIR OUTLET
10) CONCEALED WHEELS
11) DIGITAL REMOTE CONTROL
(11)
