Argo IRO User Manual

V 01/19
25
The unit must be placed vertically for 2 hours before the first power on.
APPLIANCE START-UP
Open the packaging and remove the box from above. Remove the product and the other elements supplied
(illustrated in the box below).
LCD remote control
Type AAA batteries
for the remote control
(not included)
Round fitting for window (1) to be
positioned between the end of the
tube and the end fitting for the
window
Hose
End fitting for window (2)
Drainage pipe.
Window unit kit (A+B)
Window unit (A)
Cap (B)
Position the product vertically on a flat and stable surface, as close as possible to a window and at least 50 cm from walls
or other nearby obstacles.
USE WITH END FITTING FOR WINDOW
(1)

Argo IRO Specifications

General

Type	Monobloc mobile air conditioner
Cord length	1.5 m
Noise level	65 dB
Hose diameter	150 mm
Number of speeds	3
Remotely operated	Yes
Airflow (high speed)	24 m³/h
Cooling capacity (max)	10000 BTU/h
Air conditioner functions	Cooling
Cooling capacity in watts (nominal)	2720 W
Heating capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.6
Display type	LED
Product color	White
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	1.1 kWh
Hourly energy consumption (heating)	- kWh

Weight and Dimensions

Depth	382 mm
Width	470 mm
Height	770 mm
Weight	28000 g
