Argo IRO User Manual

V 01/19
26
Connect the flat fitting to the hose, extend the hose as far as
necessary for reaching the outside and it connect to the back
of the air conditioner.
Connect the round window fitting (1) to the end of the hose
then the end fitting for the window (2)
Open the windows and lock one of the two leaves with
the handle.
Place the end fitting against the fixed leaf of the window,
and draw the other leaf towards it.
UTILIZZO CON KIT OBLÒ
1. To make the hole in the glass it is advisable to take
the porthole kit accessory to the glazier.
2. Insert the window unit (B) into the window.
3. Insert the round fitting (A) into the retractable flexible pipe
and insert the latter with its round fitting into the window unit
without the plug..
4. If the air conditioner is not used for prolonged periods,
disconnect the pipe and plug the window unit.
Connect the power cord to a suitable electric socket (220–240 V). Insert the supplied batteries into the remote control and
make sure the poles match. Select the desired operating mode from the remote control.
HOW TO USE THE APPLIANCE

Argo IRO Specifications

General

Type	Monobloc mobile air conditioner
Cord length	1.5 m
Noise level	65 dB
Hose diameter	150 mm
Number of speeds	3
Remotely operated	Yes
Airflow (high speed)	24 m³/h
Cooling capacity (max)	10000 BTU/h
Air conditioner functions	Cooling
Cooling capacity in watts (nominal)	2720 W
Heating capacity in watts (nominal)	- W
Cooling energy efficiency (EER, W/W)	2.6
Display type	LED
Product color	White
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A
Energy efficiency class (heating)	No
Hourly energy consumption (cooling)	1.1 kWh
Hourly energy consumption (heating)	- kWh

Weight and Dimensions

Depth	382 mm
Width	470 mm
Height	770 mm
Weight	28000 g
