16
V 11/13
TRANSITION FROM COOLING MODE TO HEATING MODE
REAR VIEW
Disconnect the flexible hose and the connector, rotate 180° the unit.
Insert the connector for cold air expulsion and the flexible hose on the rear of the appliance.
USE WITH TERMINAL CONNECTION FOR WINDOW
Connect the end part of the flexible hose (5) to the flat
connector (4).
Open the windows and block one of the two leafs with
the handle.
Rest the terminal connection on the fixed leaf, bring the other leaf of the window close.
Avoid tight curves and folds in the flexible hose.
Connect the power cord to a suitable electrical socket (220-240V).
HOW TO USE THE APPLIANCE
This appliance can be used to Cool, Dehumidify and Heat. In changing from one mode to another, the fan continues to
operate but the compressor stops; the compressor starts up again 3 and a half minutes later. This delay in start-up
protects the compressor from any damages.
IMPORTANT!
For Cooling and Dehumidifying mode, please position the air-conditioner with the control panel and the widest air outlet
fitted with deflector in front of you and set Cooling or Dehumidifying mode by the FUNC key on the control panel or
the remote control (see chapter OPERATING MODES).
To operate in Heating mode, the appliance must be rotated 180º so as to have control panel upside down and the smallest
air outlet fitted with deflector in front of you. Then set Heating mode by the FUNC key
on the control panel or the
remote control (see chapter OPERATING MODES).
