Argon 18 nitrogen - Brake Pads Spacing

NITROGEN : 5. Brake pads spacing
IMPORTANT : If the brake bad spacing is
too thick, the brake arm can rub on the
frame down tube. Make sure the pads
spacing is appropriate.
Adjust brake pads according to the
width of your rims:
- You can congure the brake pads
spacers with 1mm (17h), or 2mm (17i)
depending of the rim width you are
using.
18
Spacers required according
to the rim width
Rim width Spacer combinaison
19mm 2mm spacer
(e.g.: Shimano C50)
24mm + 1mm spacer
(e.g.: 808 clincher/Enve) (thin pad may be required)
17h
17i
17h
17i
