NITROGEN : 6. Rear brake installation (continued)
Adjust brake pads according to the
width of your rims:
Pass the cable through the cable guide.
Make sure that the length of the cable
housing is sucient for the guide to
remain horizontal as it can causes
interference with the rear wheel tire.
Use the proper brake bad spacers
depending on the width of your wheels
rims.
Fix the cable to the caliper with the
6mm screw and tighten it to 6Nm.
20
6Nm
