Argon 18 nitrogen - Derailleur Hanger Adjustment

NITROGEN : 9. Derailleur hanger adjustment
The front derailleur hanger (6) can
be adjusted according to the front
derailleur angle in order to get an equal
curve between the derailleur and the
big chain ring. Once at the right angle,
use blue 242 LockTite and screw both
screws in at 4Nm.
24
LOCTITE
LOCTITE
6
