Components - Parts
Please check you have all the parts listed below
2
Left armrest x 1
2
Back rest x 1
1
3
4
Right armrest x 1
Seat board x 1
Front board x 1
If you have damaged or missing components,
call the Customer Helpline: 03456 400 800
Connector x 1
Note:
The quantities
below are the correct amount to complete the assembly. In some cases more
A
B
15mm Screw x 2
C
D
E
Metal washer x 18
25mm Screw x 8
fittings may be supplied than are required.
Please check you have all the fittings listed below
Nut x 8
R uler - Use this ruler to help correctly identify the screws
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
110 115 120 125 130 135 140 145 150 155 160 165 170
105
Comonents - Fittings
5
Cushion x 1
6
F
Plastic washer x 8
Allen key x 1
Tools required
Wrench x 1
