3-7 Trouble shooting
Malfunction status
Check item
1. No action after power on.

Module is installed properly?

Power wiring is correct?

Main power switch is malfunction?

Module is malfunction?
2. F1 or F2 fuse break indicator bright.

Change the fuse accord with the
brightly indicator.
3. Display " ".

Module is installed properly?

Thermocouple is break?

Extension cable is loose or breaks?

Module is malfunction?
4. Display " ".

Thermocouple is reverse?

Module is malfunction?
5. No display PV nor m ally or PV unstabl e.

Refer to item 3.

Power leakage?

The ground is properly?
6. In the normal operation, the temperature
cannot rise up.

Module is installed properly?

Extension cable is loose or breaks?

Heater is malfunction?

Module（TRIAC）is malfunction?
7. Temperature control is unstable.

Refer 1-4-10, execute PID self –
tuning.
