ARICO Technology Co., Ltd. -1-
Chapter 1 TC5F TEMPERATURE
CONTROL MODULE
1-1 Feature
■ Dual SV temperature control.
■ Tri lines LED display.
■ Auto /Manual function.
■ PID auto temperature control.
■ Selectable two thermocouple types.(J or K)
■ Selectable two temperature scales.(°C or °F)
■ Selectable six alarm modes.
■ Selectable two trigger output modes.(Zero cross or phase angle)
■ Fuse break indicator.
■ Electric current, output percentage, frequency for power display function.
■ Heater breaks, shorts out, wears out to detect and examine the function.
■ Thermocouple break and inverse detect.
■ T h e r m o c o u p l e r a n g e K T Y P E : 0 ~ 60 0 °C (3 2 ~9 9 9 °F)/J T Y P E : 0~60 0 °C (3 2 ~99 9 °F).
■ RS485 communication: ASCII and RTU molding.
1-2 Specification
■ Power input: 230VAC±15%
■ Power frequency: 50/60Hz
■ Power consumption: 7W
■ Input impedance: 10M Ω
■ Output wattage: 3600W(Max)、15A/240VAC (
Every module)
■ Storage temperature: -20~70℃
■ Working temperature: 0~50℃
■ Work Humidity: 10~80%RH (Non-condensing)
■ Control accuracy: ±0.25%
■ Measurement accuracy: ±0.25%
