Arico tc5f - 1-3 Faceplate; 1-3-1 Faceplate description

-2-
1-3 Faceplate
1-3-1 Faceplate description
(1) PV:
1.Normal mode: Present value
2.Parameter mode: Parameter name
(2) SV:
1.Normal mode: Setting value
2.Parameter mode: Parameter name
3.M a n u a l o u t p u t o r p a r a m e t e r : M a n u a l o u t p u t %
(3) A u x . d i s p l a y : o u t p u t p e r c e n t a g e , e l e c t r i c c u r r e n t ,
f re q u e n c y d i s p l a y .
(4) P A G E k e y : P a r a m e t e r l e v e l a n d p a r a m e t e r s e l e c t
k e y .
(5) Set key: Set enable and digital shift key.
(6) Increment key: Setting number increase.
(7) Decrement key: Setting number decrease.
(8) Aux. di splay P AGE ke y: Par amete r select ke y
(9) PID tuning indicator: In PID tuning, pro gre ss
indicator flashes.
(10)Man ual o utput: Li ght up whe n Ma nua l outp ut
(11)A l a r m i n d i c a t o r : L i g h t u p w h e n a l a r m h a p p e n .
(12) o u t p u t i n d i c a t o r : L i g h t u p w h e n i n s t r u m e n t o u t p u t
(13) C o o l i n d i c a t o r : W h i l e c o o l i n g t h e i n d i c a t o r l a m p i s o n
(14) Fuse 1 ind ica tor: Ligh t up w hen fu se 1 b rea k
(15) Fuse 2 ind ica tor: Ligh t up w hen fu se 2 b rea k
(16) Power switch
(1)
(2)
(3)
(4)
(6)
(7)
(16)
(14)
(13)
(12)
( 1 1 )
(10)
(9)
(8)
(5)
(15)
