Chapter 2 CABINET
2-1 Dimension
Unit：mm
Cabinet
A
B
C
D
1 Zone
188
96
248
30
2 Zones
215
223
299
45
4 Zones
323
6 Zones
424
8 Zones
524
12 Zones
726
