FOR MODELS: JGI, JGM, JGN, JGP AND JGQ SECTION 2 - INSTALLATION
PAGE 2-8 9/08
TABLE 2-2 Rexnord AMR/CMR Couplings - Face Angular TIR
Coupling Size Flange OD, In. (cm) Angular TIR, max., In. (mm)
162 4.594 (11.7) 0.005 (0.13)
200 5.750 (14.6) 0.005 (0.13)
225 6.000 (15.2) 0.005 (0.13)
262 6.875 (17.5) 0.005 (0.13)
312 8.125 (20.6) 0.005 (0.13)
350 9.125 (23.2) 0.005 (0.13)
375 10.063 (25.6) 0.005 (0.13)
425 11.000 (27.9) 0.005 (0.13)
450 11.875 (30.2) 0.005 (0.13)
500 13.438 (34.1) 0.005 (0.13)
550 15.000 (38.1) 0.005 (0.13)
600 16.750 (42.6) 0.005 (0.13)
700 18.938 (48.1) 0.0055 (0.14)
750 20.625 (52.4) 0.0059 (0.15)
800 22.375 (56.8) 0.0064 (0.16)
850 23.750 (60.3) 0.0068 (0.17)
925 25.750 (65.4) 0.0074 (0.19)
1000 28.250 (71.8) 0.0081 (0.21
1100 30.250 (76.8) 0.0087 (0.22)
1200 33.375 (84.8) 0.0096 (0.24)
1300 36.000 (91.4) 0.0104 (0.26)
1550 39.250 (99.7) 0.0113 (0.29)
