6. Orient the chute and pedestal to its most
vertical position and tighten pedestal
hardware to 15 – 31 lbf-ft (20 – 42 N•m)
(Figure 10).
Install Discharge Chute, Chute
Control and Chute Rod
(Models 921028, 029)
(Figures 12, 13 and 14)
1. Grease underside of discharge chute
ring (if not already greased).
2. Remove mounting hardware from auger
housing.
3. Install discharge chute over opening in
the auger housing. Finger tighten the
mounting hardware removed in step 2.
NOTICE: Leave discharge chute pedestal
loose to help install the chute rod.
4. Remove the gear cover from top of
chute pedestal.
5. Release the lock arm on the gear
assembly with your finger and rotate the
discharge chute so it points straight
ahead.
NOTICE: Make sure alignment markers on
gear assembly are lined up when discharge
chute is pointing straight ahead.
6. Remove rubber grommet from control
panel.
7. Make sure the chute control cable is
routed between the lower handlebar and
the bottom of the control panel, insert
control assembly into slot in control
panel from below and install assembly
into nylon bushing in control panel. See
Figure 13.
8. Reinstall rubber grommet over control
assembly knob and into control panel.
Figure 11
1. Chute Crank
2. Control Panel
3. Hairpin
1
3
2
Models 921023, 024, 030, 032, 035, 036,
037
1
5
3
2
4
Figure 12
1. Mounting Holes
2. Discharge Chute
3. Chute Pedestal
4. Discharge Chute Ring
5. Mounting Hardware
